1 – WHAT IS ANTI-SLIP CORRUGATED BOARD?
Anti-slip corrugated board is corrugated board coated on both sides with an anti-slip layer. These anti-slip sheets are essential accessories for stabilising your products on pallets. Particularly during internal conveying, storage and transport of your goods.
They have been specially designed to hold products in place. Particularly during transport, when pallets are subject to longitudinal movements (acceleration and braking) and lateral movements (bends, roundabouts).
The product achieves a slip coefficient > 0.42°, compared with 0.20° for a standard corrugated sheet.
CGP COATING INNOVATION is constantly innovating, working with you to design solutions tailored to your needs. This is why the group has manufactured a complete range of anti-slip corrugated board, varying the compositions according to your logistical needs. We offer different types of E, B and EB flute, compositions of 350, 400 and 600 g/m², and two types of anti-slip coating with a slip coefficient > 0.42° and Extra anti-slip > 0.60°.
Discover the full range: STABULON E400; STABULON B400; STABULON B600 and STABUSTOP B400.
2 – WHY USE ANTI-SLIP CORRUGATED BOARD?
STABULON® anti-slip corrugated board has been specially developed for packaging with an irregular surface and/or a small contact area with the liner, providing good load distribution and high rigidity.
STABULON® anti-slip corrugated board pallet insert
The anti-slip corrugated cardboard format allows the asperities to fit within the cardboard sheet and stabilise the packaged products on the pallet. The board is highly resistant to perforation, punching and shearing.
This limits product slippage and damage. So your products are shipped in complete safety. In addition, the high rigidity of anti-slip corrugated board sheets creates a rigid, stable platform on which products can be stacked in many layers.
3 – HOW TO USE ANTI-SLIP CORRUGATED BOARD
Anti-slip corrugated board is used :
- At the foot of the pallet to prevent rising damp, protect the products from the roughness of the pallet and stabilise the first layers of products. In this way, the link between the wood or plastic pallet and the load is ensured.
- Between layers of palletised products to increase rigidity and product stability, and possibly increase the height of palletised products.
- On top of the pallet when products are packaged on stacked pallets. This prevents slipping and rubbing. The last layer of products is also protected against the aggression of the wooden pallet and against dust and bad weather.
4 – WHAT ARE THE ADVANTAGES OF USING NON-SLIP CORRUGATED CARDBOARD?
The various advantages :
- Its very high rigidity, for planning layers of irregular products e.g. bags, bottles etc.
STABULON® anti-slip corrugated cardboard insert
- Its cushioning capacity, when the product to be palletised is heavy or has a small contact surface. It is secured to the inside of the sheet and prevents products from sliding off the pallet.
5 – EXAMPLES OF USE
STABULON® corrugated anti-slip pad Example in action
Our experts can advise you on the choice and testing of solutions adapted to your needs. Our extensive range covers all applications: manual pallet assembly, pallet assembly by a palletiser, high level and low level systems, palletising robots.
